φ60mm 3.0V 3000F EDLC Supercapacitor cells
Electrical Specifications
| TYPE | C60W-3R0-3000 |
| Rated Voltage VR |
3.0 V |
| Surge Voltage VS1 |
3.1 V |
| Rated Capacitance C 2 |
3000 F |
| Capacitance Tolerance 3 |
-0% / +20 % |
| ESR2 | ≤0.23 mΩ |
| Leakage Current IL 4 |
<12 mA |
| Self-discharge Rate 5 |
<20 % |
| Constant Current IMCC(ΔT = 15°C)6 | 142 A |
| Max Current IMax7 | 2.66 kA |
| Short Current IS8 | 13 kA |
| Stored Energy E 9 | 3.75 Wh |
| Energy Density Ed 10 | 7.4 Wh/kg |
| Usable Power Density Pd11 | 9.3 kW/kg |
| Matched Impedance Power PdMax 12 |
19.4 kW/kg |
Thermal Characteristics
| Type | C60W-3R0-3000 |
| Working Temperature |
-40~65 °C |
| Storage Temperature13 |
-40~70 °C |
| Thermal Resistance RTh14 | 3.2 K/W |
| hermal Capacitance Cth15 | 575 J/K |
Lifetime Characteristics
| TYPE | C60W-3R0-3000 |
| DC Life at High Temperature 16 |
1500 hours |
| DC Life at RT17 |
10 years |
| Cycle Life18 |
1,000,000 cycles |
| Shelf Life19 |
4 years |
Saferty & Environmental Specifications
| TYPE | C60W-3R0-3000 |
| Safety |
RoHS, REACH and UL810A |
| Vibration |
ISO16750 Table 12 IEC 60068-2-64 (Table A.5/A.6) |
| Shock |
IEC 60068-2-27 |
Physical Parameters
| TYPE | C60W-3R0-3000 |
| Mass M |
505 g |
| Terminals(leads)20 |
Weldable |
| Dimensions21 Height |
138 mm |
| Diameter |
60 mm |
